ISOLA PCB High TG Stable DK Value High Frequency Circuit Board
Quick detail:
Size: 18*10cm
Copper THK:35UM
Color: Green
Material: Isola laminate
Surface finish:Immersion gold,ENIG
6 layer 1.2mm thickness
Green solder mask,white silk screen
Line space and width:10mil
Certification:ISO9001/SGS/UL
Delivery time:3-7 working days
Most popular isola PCB material model:
Isola fr402,370HR,fr408,Isola410
| Isola PCB |
| Isola laminate |
| Isola fr406 |
| Isola 410 |
| Isola 370HR |
Isola PCB laminate Advantage:
Have stock of Scarcity of isola 370HR material,
short time of incoming material,save costing for you
Isola substrate is a high performance 180°C glass transition temperature
(Tg) FR-4 system for multilayer Printed Wiring Board (PWB)
applications where maximum thermal performance and reliability
are required. 370HR laminate and prepreg products are
manufactured with a unique high performance multifunctional
epoxy resin, reinforced with electrical grade (E-glass) glass fabric.
This system provides improved thermal performance and low
expansion rates in comparison to traditional FR-4 while retaining
FR-4 processability.
In addition to this superior thermal performance, the mechanical,
chemical and moisture resistance properties all equal or exceed
the performance of traditional FR-4 materials. The 370HR system
is also laser fluorescing and UV blocking for maximum compatibility
with Automated Optical Inspection (AOI) systems, optical positioning
systems and photoimagable solder mask imaging.
370HR has proven to be best in class for sequential lamination
Isola PCB Features
• High Thermal Performance
Tg: 180°C (DSC)
Td: 360°C (TGA @ 5% wt loss)
• T260: 60 minutes
• T288: 15 minutes
• RoHS Compliant
• UV Blocking and AOI Fluorescence
High throughput and accuracy during PCB
fabrication and assembly
• Superior Processing
Closest to conventional FR-4 processing of all
high speed materials
• Core Material Standard Availability
Thickness: 0.002″ (0.05 mm) to 0.125″
(3.2 mm)
Available in full size sheet or panel form
• Prepreg Standard Availability
Roll or panel form
Tooling of prepreg panels available
• Copper Foil Type Availability
Standard HTE Grade 3
RTF (Reverse Treat Foil)
• Copper Weights
1 and 2 oz (18, 35 and 70 μm) available
Heavier copper available upon request
Thinner copper foil available upon request
• Glass Fabric Availability
Standard E-glass
Square weave glass fabric available
• Industry Approvals
IPC-4101D WAM1 /24 /121 /124
UL - File Number E41625
Qualified to UL's MCIL Program
